Description
MATERIAL SPECIFICATIONS
Fitting Body:
Fabricated Fittings: 1"-12" 304L/316L stainless steel conforming to ASTM A403 WPW or A403CR, Schedule 10 and Schedule 40
Full Flow Fittings: 1"-12" 304L/316L stainless steel conforming to A403 WPW or A403CR, Schedule 10 and Schedule 40
Sizes 14" and above in 304L/ 316L stainless steel conform to A774 or A403CR or A403WPW Schedule 10 •
Fittings are available in full flow and fabricated versions in 304L and 316L.
MAXIMUM WORKING PRESSURE
Pressure ratings for the stainless steel fitting are equal to the pressure rating of the coupling that is installed on stainless steel pipe with equal wall thickness.
GENERAL NOTES
- Pressure Ratings for fittings conform to the working pressure of the coupling used to join the system.
- Listed and or Approved Pressures are pressure ratings for fire protection systems, tested and approved by various approval bodies.
- Field Joint Test: For one time only the system may be tested hydrostatically at 1½times the maximum working pressure listed (AWWA C606 5.2.3).
- Warning: Piping systems must always be depressurized and drained before attempting disassembly and or removal of any components.
- GroovJoint reserves the right to change specifications, designs and or standard without notice and without incurring any obligations.
