Description
This accessory is used for submersed installation of Grundfos wastewater pumps.
This set consists of:
•Baseplate
•Guide claw*
•Upper guide rail holder (Guide rails are not included)
•Bolts and gasket for mounting the guide claw to the pump, when needed.
*For pumps with outlet flanges sized DN 250 and above, the guide claw is fitted to the pump from the factory
Specs
Material: Cast iron
Gasket: Rubber
Maximum operating pressure: 145.04 psi
Type of inlet/outlet connection: ANSI
Size of suction port: ANSI
Flange pressure class: CLASS 150
Flange standard: ANSI-B 16.5
Number of anchor bolts: 0
Number of base units: 1
Number of washers: 0
Number of nuts: 2
Number of gaskets: 1
Number of profile gaskets: 1
Number of guide claws: 1
Number of screws: 8
Number of guide rail holders: 1
Flange standard: ANSI-B 16.5
Number of anchor bolts: 0
Number of base units: 1
Number of washers: 0
Number of nuts: 2
Number of gaskets: 1
Number of profile gaskets: 1
Number of guide claws: 1
Number of screws: 8
Number of guide rail holders: 1
