Description
Grundfos CMBE 1-44
The Grundfos CMBE 1-44 Booster is designed for domestic and commercial water supply, pressure boosting, irrigation, and dewatering applications. The CMBE series is available in both 1x110-120V and 1x200-240V variants and uses energy-efficient, permanent magnet motor technology, which provides unmatched reliability, quiet operation, and energy savings. Thanks to the integrated speed controller, the CMBE 1-44 keeps a constant pressure in the pipe system. A pressure sensor monitoring discharge pressure will signal the speed controller to change the motor speed to adapt the performance to the new situation.
Features
• Constant pressure, integrated speed control• compact
• Robust, stainless steel
• Easy installation
• Dry run protection specs:
Liquid:
Pumped liquid: WaterLiquid temperature range: 32 .. 140 °F
Selected liquid temperature: 68 °F
Density: 62.29 lb/ft³
Technical:
Pump speed on which pump data is based: 3780 rpm
Rated flow: 10.6 US GPM
Rated head: 97.77 ft
Primary shaft seal: AQQE
Approvals and markings: CE, CULUS
Curve tolerance: ISO9906:2012 3B
Return valve: YES
Start pressure: Integrated Frequency converter
Materials:
Pump housing: Stainless steelDIN W.-Nr. 1.4301
AISI 304
Impeller: Stainless steel
DIN W.-Nr. 1.4301
Installation:
t max amb: 131 °F
Flange standard: INTERNAL NPT THREAD
Pump inlet: NPT 1
Pump outlet: NPT 1
Electrical data:
Rated power - P2: 1.01 HP
Main frequency: 50 / 60 Hz
Rated voltage: 1 x 115 V
Maximum current consumption: 8 A
Rated speed: 360-4000 rpm
Enclosure class (IEC 34-5): IP55
Insulation class (IEC 85): F
Type of cable plug: US 5-15
Mains cable: 4.92 ft
Tank:
Tank volume: 0.528 gal
Manuals
* The manufacturer recommends using the Grundfos 98046408 MI 301 Go Remote for optimal setup and troubleshooting of this pump.
