  • Grundfos 99503875 CMBE TWIN 10-54 Booster Pump 200-240V, 108 GPM, 2 HP
  • Grundfos 99503875 CMBE TWIN 10-54 Booster Pump 200-240V, 108 GPM, 2 HP

Grundfos 99503875 CMBE TWIN 10-54 Booster Pump 200-240V, 108 GPM, 2 HP

mpn: 99503875 SKU: GR99503875 UPC: 5713830163740
(No reviews yet) Write a Review
$8,791.00
In Stock
Get it by Ships in 1 business day
Your Zip code helps us provide the most accurate delivery information.

Manuals (3)

Manual_Specification Sheet Manual_Flyer-CMBE-Twin Manual_Data-Booklet-CMBE-Twin
Free Shipping This product ships free.
Easy Returns 90 day return policy.

Description

Note: Per the manufacturer, not installing the Grundfos 91136184 Inlet Pressure Switch Kit may invalidate the warranty.

Deliver constant pressure with the Grundfos CMBE Twin 10-54 booster pump for water supply and commercial applications. The Grundfos Twin Booster pump system consists of two CMBE pumps connected in parallel and mounted on a base plate with a Grundfos-built manifold. The CMBE pumps will alternate to ensure the same number of operating hours until the high flow is needed, and the pumps will run together.

The Grundfos CMBE Twin 10-54 Booster consists of 2 units of CMBE Booster which each include,

  • 5-way valve
  • Expansion tank
  • Pressure gauge
  • Pressure sensor

Features:

  • Cascade multi-pump operation
  • Automatic pump alternation
  • Constant pressure control
  • Pipe filling
  • Compact design
  • Robust, stainless steel
  • Easy installation (Plug & Pump)
  • Dry run protection

* The manufacturer recommends using the Grundfos 98046408 MI 301 Go Remote for optimal setup and troubleshooting of this pump.

Grundfos 99503875 CMBE TWIN 10-54 Booster Pump 200-240V, 108 GPM, 2 HP

(No reviews yet) Write a Review
mpn
99503875
SKU:
GR99503875
UPC:
5713830163740
Width:
29.00 (in)
Height:
34.00 (in)
Depth:
40.00 (in)
  • Grundfos 99503875 CMBE TWIN 10-54 Booster Pump 200-240V, 108 GPM, 2 HP
  • Grundfos 99503875 CMBE TWIN 10-54 Booster Pump 200-240V, 108 GPM, 2 HP
$8,791.00

Description

Note: Per the manufacturer, not installing the Grundfos 91136184 Inlet Pressure Switch Kit may invalidate the warranty.

Deliver constant pressure with the Grundfos CMBE Twin 10-54 booster pump for water supply and commercial applications. The Grundfos Twin Booster pump system consists of two CMBE pumps connected in parallel and mounted on a base plate with a Grundfos-built manifold. The CMBE pumps will alternate to ensure the same number of operating hours until the high flow is needed, and the pumps will run together.

The Grundfos CMBE Twin 10-54 Booster consists of 2 units of CMBE Booster which each include,

  • 5-way valve
  • Expansion tank
  • Pressure gauge
  • Pressure sensor

Features:

  • Cascade multi-pump operation
  • Automatic pump alternation
  • Constant pressure control
  • Pipe filling
  • Compact design
  • Robust, stainless steel
  • Easy installation (Plug & Pump)
  • Dry run protection

* The manufacturer recommends using the Grundfos 98046408 MI 301 Go Remote for optimal setup and troubleshooting of this pump.

View AllClose

Warranty Information

2 years
View AllClose

Additional Information

alsoNeedIDs:
17068,5213
alsoNeedLabel:
You Will Also Need
Spec_Main frequency:
60 Hz
Spec_Rated flow:
108 US GPM
Spec_Rated head:
82.35 ft
Spec_Impeller:
Stainless steel DIN W.-Nr. 1.4301
Spec_Pump housing:
Stainless steel DIN W.-Nr. 1.4301 AISI 304
Spec_Tank volume:
1.057 gal
Spec_Primary shaft seal:
AQQE
Spec_Curve tolerance:
ISO9906:2012 3B
Spec_Pumped liquid:
Water
Spec_Liquid temperature range:
32 .. 140 °F
Spec_Selected liquid temperature:
68 °F
Spec_Density:
62.29 lb/ft³
Spec_Rated voltage:
1 x 200-240 V
Spec_Enclosure class (IEC 34-5):
IP55
Spec_Insulation class (IEC 85):
F
Spec_Pump speed on which pump data is based:
3780 rpm
Spec_Approvals and markings:
CE, CULUS
Spec_Start pressure:
Integrated Frequency converter
Spec_Main pump type:
CMBE 10-54
Spec_Main pump product number:
99503806
Spec_Rubber:
EPDM
Spec_t max amb:
104 °F
Spec_Flange standard:
INTERNAL NPT THREAD
Spec_Pump inlet:
NPT 2
Spec_Pump outlet:
NPT 2
Spec_Rated power - P2:
2 HP
Spec_Maximum current consumption:
8 A
Spec_Rated speed:
360-4000 rpm
Spec_Type of cable plug:
FUSE
Spec_Mains cable:
4.92 ft
Manual_Specification Sheet:
https://24hr.supply/content/99503875_CMBE_TWIN_1054_IUCBDH.pdf
Manual_Flyer-CMBE-Twin:
https://24hr.supply/content/grundfos/twin%20booster/Flyer-CMBE-Twin.pdf
Manual_Data-Booklet-CMBE-Twin:
https://24hr.supply/content/grundfos/twin%20booster/Data-Booklet-CMBE-Twin.pdf
