Description
Features
- Passivated 444 stainless steel alloy tank and heat exchanger with superior corrosion protection
- 1” O.D. stainless steel heat exchanger coil - low restriction minimizes pressure drop
- 2” non-CFC foam insulation covers the sides and top of tank, for rigidity, improved efficiency and less energy consumption
- Front Boiler Connections for easier installation
- Includes T&P valve and aquastat with stainless steel well
- Factory installed sediment reducing inlet tube reduces sediment build
Specs
- Capacity: 120 Gallons
- First Hour Delivery Rating (Gal): 409
- Continuous Draw @135°F 319
- Standby Heat Loss Rating (°F/Hr.): 0.3
- Minimum Heat Required Rate (BTU/Hr.): 199,000
- Minimum Heat Source Flow Rate (Gal./Min.): 9.0
