Schier GB-50, High-Flow, 50 GPM Hydromechanical Grease Interceptor w/ Cast Iron Cover (Liquid Capacity: 65 Gal. Grease Capacity: 439.5 lbs. (60 gal.)

(No reviews yet) Write a Review
SKU:
GB-50-CI
Width:
37.00 (in)
Height:
28.50 (in)
Depth:
32.25 (in)
  • Schier GB-50, High-Flow, 50 GPM Hydromechanical Grease Interceptor w/ Cast Iron Cover (Liquid Capacity: 65 Gal. Grease Capacity: 439.5 lbs. (60 gal.)
  • Schier GB-50, High-Flow, 50 GPM Hydromechanical Grease Interceptor w/ Cast Iron Cover (Liquid Capacity: 65 Gal. Grease Capacity: 439.5 lbs. (60 gal.)
  • Schier GB-50, High-Flow, 50 GPM Hydromechanical Grease Interceptor w/ Cast Iron Cover (Liquid Capacity: 65 Gal. Grease Capacity: 439.5 lbs. (60 gal.)
  • Schier GB-50, High-Flow, 50 GPM Hydromechanical Grease Interceptor w/ Cast Iron Cover (Liquid Capacity: 65 Gal. Grease Capacity: 439.5 lbs. (60 gal.)
  • Schier GB-50, High-Flow, 50 GPM Hydromechanical Grease Interceptor w/ Cast Iron Cover (Liquid Capacity: 65 Gal. Grease Capacity: 439.5 lbs. (60 gal.)
$2,449.30

Description

This tank ships with 1 T24-GI cast iron cover

The GB-50 offers best-in-class certified grease capacity and 20% kitchen solids waste capacity. It can be installed above grade (on the ground) or buried below grade (compatible with FP24 riser to bring system to grade), as well as indoor or outdoor. The triple outlet feature allows for installation flexibility, including the ability to connect an unused outlet for remote pump out (PP3 compatibility).

Features

  • Rugged polyethylene tank body
  • No flow control required, first in the industry certified to Type D of the ASME standard
  • Safety Star access restrictor prevents accidental entry
  • Fits through 36" doorways
  • One cast iron cover

Specs

  1. 4" FPT inlet/outlet with 4" plain end adapters, single inlet, and triple outlet.
  2. Unit weight: 78 lbs. For wet weight, add 542 lbs. For traffic-rated cover, add 90 lbs per cover. For pedestrian cover, add 7 lbs per cover.
  3. Maximum operating temperature: 150º F continuous
  4. Capacities - Liquid: 65 gal. Grease: 439.5 lbs. (60 gal.) @50 GPM Solids: 13 gal.
  5. For gravity drainage applications only.
  6. Do not use it for pressure applications.
  7. Vent not required unless per local code.
  8. Engineered inlet and outlet diffusers with inspection ports are removable to inspect/clean piping.
  9. Integral air relief / Anti-siphon / Sampling access.
  10. Designed for below-grade, above-grade, indoor or outdoor installations.
  11. Safety Star (450 lbs load capacity) is an access restrictor built into each cover adapter to prevent accidental entry into tanks
